| Video |
| Imaging Device |
1/2.8" CMOS |
| Resolution |
1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
| Max. Framerate |
H.265/H.264: Max. 60fps/50fps(60Hz/50Hz)
MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
| Min. Illumination |
Couleur: 0.05Lux(F1.6, 1/30sec, 30IRE)
BW: 0.005Lux(F1.6, 1/30sec, 30IRE), 0Lux(IR LED On) |
| Lens |
| Focal Length (Zoom Ratio) |
4.44~111mm(25x) zoom (digital 32x, total 800x zoom) |
| Max. Aperture Ratio |
F1.6(Wide)~F3.9(Tele) |
| Angular Field of View |
H: 64.66°(Wide)~2.99°(Tele)
V: 38.08°(Wide)~1.68°(Tele) |
| Min. Object Distance |
Wide: 1.5m(4.92ft) / Tele: 2m(6.56ft) |
| Focus Control |
Oneshot AF, Focus save |
| Lens Type |
DC auto iris |
| Pan / Tilt / Rotate |
| Pan Range |
360° Endless |
| Pan Speed |
Preset: 700°/sec, Manual: 0.024°/sec~250°/sec |
| Tilt Range |
110°(0°~110°) |
| Tilt Speed |
Preset: 300°/sec, Manual: 0.024°/sec~250°/sec |
| Sequence |
Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule |
| Preset Accuracy |
±0.2° |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Direction Indicator |
Support |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, HLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNRⅤ |
| Digital Image Stabilization |
Support(built-in gyro sensor) |
| Désembuage |
Support |
| Motion Detection |
8ea, 8point polygonal zones |
| Privacy Masking |
32ea, 4point quadrangle zones
- Couleur: Grey/Green/Red/Blue/Black/White
- Solid/Mosaic |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) |
| Video Rotation |
Flip, Mirror |
| Analytics |
Analytics events
- Directional detection, Détection de mouvement, Enter/Exit, Tampering, Virtual line
* Audio detection(Via optional I/O box SPM-4210) |
| Alarm Triggers |
Analytics, Network disconnect
* Alarm input((Via optional I/O box SPM-4210) |
| Alarm Events |
When alarm trigger occurred
- File upload(image) : e-mail/FTP
- Notification : e-mail
- Recording : SD/SDHC/SDXC or NAS recording at event triggers
- Alarm output
- Handover(PTZ preset, Send message by HTTP/HTTPS/TCP)
* Alarm output / Audio clip playback(Via optional I/O box SPM-4210) |
| Light Type |
IR LED (850nm) |
| IR Viewable Length |
100m(328.08ft) |
| Auto Tracking |
Support |
| Network |
| Ethernet |
Metal shielded RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast
Streaming multiple(jusqu'à 10 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast), NTCIP1205 |
| Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
| Security |
| OS / Firmware Protect |
Firmware encryption |
| User authentication |
Digest Authentication, Privent brute-force attack |
| Network authentication |
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) |
| Secure Communication |
HTTPS, SRTP, WSS(Websocket secure) |
| Access Control |
IP address filtering |
| Data Protect |
Authentication information encryption, ZIP compression encryption |
| Audit |
User Access/System/Event log |
| Device ID |
Device Certificate(Hanwha Techwin Root CA, pre-installed) |
| General |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot Max. 256GB |
| Memory |
1GB RAM, 256MB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-35°C~+55°(-31°F ~ +131°F)
* Start up should be done at above -30°C
0~95% RH(non-condensing) |
| Storage Temperature / Humidity |
-50°C~+60°C(-58°F~+140°F) / 0~95% RH |
| Certification |
IP66, IK10, NEMA4X |
| Input Voltage |
PoE+(IEEE802.3at, Class4) |
| Power Consumption |
PoE+: Max. 25.5W, typical 14.7W |
| Mechanical |
| Couleur / Material |
Body : White / Aluminum
Head : Black / Polycarbontate
Hard-coated dome |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
ø158x293.3mm(ø6.22x11.55"), 3100g(6.83lb) |
| Hanging Mount (Dome) |
SBP-156HMW |
| Ceiling Mount (Assy) |
SBP-156CMW, SBP-300CMTS, SBP-300CMW1/900CMW, SBP-150CMI/300CMI |
| Wall Mount |
SBP-156WMW, SBP-390WMW2 |
| Pole Mount |
SBP-300PMW2 |
| Parapet Mount |
SBP-156LMW, SBP-300LMW |
| Corner Mount |
SBP-156KMW, SBP-300KMW1 |
| Cabinet |
SBP-300NBW |
| Certifications & Standards |
| EMC |
FCC 47 CFR 15 Subpart B Class A
IC Regulation ICES-003 Issue 7 Class A
CE/UKCA
- EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3
VCCI CISPR 32 Class A
RCM AS/NZS CISPR 32 Class A |
| Safety |
UL 62368-1, CAN/CSA C22.2 NO. 62368-1
IEC/EN 62471 |
| Environment |
IEC/EN 63000
IEC/EN 60529 IP66, IEC/EN 62262 IK10 |
| DORI (EN62676-4 standard) |
| Detect (25PPM/ 8PPF) |
Wide: 60.7m(199.1ft) / Tele: 1471.3m(4827.2ft) |
| Observe (63PPM/ 19PPF) |
Wide: 24.3m(79.6ft) / Tele: 588.5m(1930.9ft) |
| Recognize (125PPM/ 38PPF) |
Wide: 12.1m(39.8ft) / Tele: 294.3m(965.4ft) |
| Identify (250PPM/ 76PPF) |
Wide: 6.1m(19.9ft) / Tele: 147.1m(482.7ft) |
