| Video |
| Imaging Device |
1/1.8" progressive CMOS |
| Resolution |
3840x2160, 3328x1872, 3072x1728, 2592x1944, 2688x1520, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 30fps(@8MP Max. 5fps) |
| Min. Illumination |
Couleur: 0.04Lux(F1.3, 1/30sec, 30IRE)
BW: 0.004Lux(F1.3, 1/30sec, 30IRE), 0Lux(IR LED on) |
| Video Out |
USB: Micro USB Type B, 1280x720 for installation |
| Lens |
| Focal Length (Zoom Ratio) |
4.4~9.3mm(2.1x) Vari-focale motorisée |
| Max. Aperture Ratio |
F1.3(Wide)~F2.15(Tele) |
| Angular Field of View |
H: 113°(Wide)~47°(Tele)
V: 58°(Wide)~26°(Tele)
D: 138°(Wide)~54°(Tele) |
| Min. Object Distance |
0.5m(1.64ft) |
| Focus Control |
Simple focus, Manual |
| Lens Type |
P-iris(IR corrected) |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
0°~360° / -45°~75° / 0°~355° |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, HLC, WDR, SSDR |
| Wide Dynamic Range |
extremeWDR(120dB) |
| Digital Noise Reduction |
WiseNRⅡ(Basée sur machines IA), SSNRⅤ |
| Digital Image Stabilization |
Support(built-in gyro sensor) |
| Désembuage |
Support |
| Motion Detection |
8ea, 8point Polygonal zones |
| Privacy Masking |
32ea, 4point Quadrangle zones
- Couleur: Gray/Green/Red/Blue/Black/White
- Mosaic |
| Gain Control |
Off / Max Gain / Manual |
| White Balance |
ATW / NarrowATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support(Fill/stretch mode) |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker(2~1/12,000sec)
prefer shutter control(Basée sur machines IA) |
| Video Rotation |
Flip, Mirror, Hallway view(90°/270°) |
| Analytics |
Classification d'objets: Detéction (Personnes/Visages/Véhicules/Plaques d'immatriculation
Attributes: Vehicle(Type: car/bus/truck/motorcycle/bicycle)
Support DetectionShot
Analyses d'événements basée AI
- Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit)
Analytics events
- Defocus detection, Détection de mouvement, Tampering, Fog detection, Audio detection, Sound classification, Shock detection, Virtual area(Appear/Disappear) |
| Business Intelligence |
Basée sur machines IA: Comptage de personnes, Gestion de queue, Heatmap |
| Alarm I/O |
2 configurable I/O ports |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input, App event, Time schedule, MQTT subscription |
| Alarm Events |
When alarm trigger occurred
- File upload(image): e-mail/FTP
- Notification: e-mail
- Recording: SD/SDHC/SDXC or NAS recording at event triggers
- Alarm output
- Handover: PTZ preset, send message by HTTP/HTTPS/TCP
- Audio clip playback
- MQTT: publication |
| Audio In |
Selectable(mic in/line in)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
| Audio Out |
Line out, Max.output level: 1Vrms |
| IR Viewable Length |
WiseIR 40m(131.23ft) |
| Network |
| Ethernet |
Metal shielded RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
| Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(Basée sur machines IA) |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast
Streaming multiple(jusqu'à 10 profiles, 3 virtual channel support) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast), MQTT |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Device Certificate(Hanwha Techwin Root CA, pre-installed)
Secure by default certificate
HTPM(Hanwha Trusted platform module)
Secure OS/Boot/Storage, Verify firmware forgery
CyberSecurity assuarance program UL CAP(UL 2900-1) |
| Application Programming Interface |
ONVIF Profile S/G/T/M
SUNAPI(HTTP API)
Wisenet open platform |
| General |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Greek, Hungarian |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot 512GB |
| Memory |
4GB RAM, 512MB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-40°C~+55°C(-40°F~+131°F)
* Start up should be done at above -20°C
0~95%RH(non-condensing)
Humidity control /w AIR vent |
| Storage Temperature / Humidity |
-50°C~+60°C(-58°F~+140°F) / 0~90% RH |
| Certification |
IP66/IP67, NEMA4X, IK10 |
| Input Voltage |
PoE(IEEE802.3af, Class3), 12VDC |
| Power Consumption |
PoE: Max 12.95W, typical 11.2W
12VDC: Max 13.2W, typical 10.8W |
| Mechanical |
| Couleur / Material |
White / Aluminum
Coupole de dôme à revêtment dur renforcés |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
ø160x118mm(ø6.30x4.65"), 1450g(3.20 lb) |
| Compatible Conduit hole / Gangbox |
12.7mm(1/2")(M20)
single, double, 4" octagon, 4" square |
| Hanging Mount (Dome) |
SBP-167HMW |
| Certifications & Standards |
| EMC |
FCC 47 CFR 15 Subpart B Class A
ICES-3(A)/NMB-3(A)
CE/UKCA
- EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3
VCCI CISPR 32 Class A
RCM AS/NZS CISPR 32 Class A
KS C 9832 Class A , KS C 9835 |
| Safety |
UL 62368-1, CAN/CSA C22.2 NO. 62368-1
IEC/EN 62471 |
| Environment |
IEC/EN 63000
IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10
NEMA 250 type 4X |
| DORI (EN62676-4 standard) |
| Detect (25PPM/ 8PPF) |
Wide: 50.8m(166.77ft) / Tele: 176.6m(579.49ft) |
| Observe (63PPM/ 19PPF) |
Wide: 20.3m(66.71ft) / Tele: 70.7m(231.80ft) |
| Recognize (125PPM/ 38PPF) |
Wide: 10.2m(33.35ft) / Tele: 35.3m(115.90ft) |
| Identify (250PPM/ 76PPF) |
Wide: 5.1m(16.68ft) / Tele: 17.7m(57.95ft) |
