| Video |
| Imaging Device |
1/2.8" CMOS: each CH |
| Resolution |
2592x1520, 1920x1080, 640x360 |
| Max. Framerate |
H.265/H.264: Max. 15fps/15fps
MJPEG: Max. 15fps(@4MP Max. 5fps) |
| Min. Illumination |
Couleur: 0.05Lux(F1.2, 1/30sec, 30IRE)
BW: 0.005Lux(F1.2, 1/30sec, 30IRE), 0Lux(IR LED on) |
| Video Out |
USB: Micro USB Type B, 2592x1520 for installation |
| Lens |
| Focal Length (Zoom Ratio) |
3.19mm Focale fixe |
| Max. Aperture Ratio |
F1.2 |
| Angular Field of View |
H: 97° / V: 54° / D: 116° |
| Min. Object Distance |
2m(6.56ft) |
| Focus Control |
Manual |
| Lens Type |
Fixed Iris |
| Mount Type |
M12 |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
0~360°(100° per CH)/ 0~75° / 0~90° |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNRⅤ, WiseNRⅡ(Basée sur machines IA) |
| Motion Detection |
8ea, 8point Polygonal zones |
| Privacy Masking |
6ea, Rectangular zones
- Couleur: Gray, Black, White |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker(1/5~1/12,000sec)
Auto Prefer shutter control(Basée sur machines IA) |
| Video Rotation |
Flip, Mirror, Hallway view(90°/270°) - Each channel separately |
| Analytics |
Classification d'objets: Detéction (Personnes/Visages/Véhicules/Plaques d'immatriculation
Attributes: Vehicle(Type: Car/Bus/Truck/Motorcycle/Bicycle)
Support DetectionShot
Analyses d'événements basée AI
- Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit)
Analytics events
- Détection de mouvement, Tampering, Virtual area(Appear/Disappear)
* Audio detection, Sound classification(via NW I/O box SPM-4210) |
| Alarm Triggers |
Analytics, Network disconnect, App event, Time schedule, MQTT subscription
* Alarm input(via NW I/O Box SPM-4210) |
| Alarm Events |
When alarm trigger occurred
- File upload(image): e-mail/FTP
- Notification: e-mail
- Recording: SD/SDHC/SDXC or NAS recording at event triggers
- Alarm output(via NW I/O box SPM-4210)
- Handover: PTZ preset, Send message by HTTP/HTTPS/TCP
- MQTT: publication |
| IR Viewable Length |
20m(65.62ft) |
| Network |
| Ethernet |
Metal shielded RJ-45(10/100/1000BASE-T) |
| Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(Basée sur machines IA) |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(10 users) / Multicast
Streaming multiple: jusqu'à 4 profiles(include preview profile)
* 4 profiles support different resolutions that are not identical |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast), MQTT |
| Application Programming Interface |
ONVIF Profile S/T/M
SUNAPI(HTTP API)
Wisenet open platform |
| Security |
| OS / Firmware Protect |
Encrypted Firmware, Secure boot, Signed Firmware |
| User authentication |
Digest Authenticaton |
| Network authentication |
IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) |
| Secure Communication |
HTTPS, WSS(WebSocket Secure) |
| Access Control |
IP-based access control |
| Data Protect |
Encryption Credentials, Encrypt compress for live recording file |
| Audit |
Access / System / Event Log management |
| Device ID |
Device certificate(Hanwha Private Root CA) |
| Secure Storage |
TPM, SDcard partition encrypt |
| Security Certificate |
TPM with FIPS 140-2 level 2 |
| General |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Greek, Hungarian |
| Edge Storage |
Micro SD/SDHC/SDXC 2slot Max. 1TB(512GBx2) |
| Memory |
4GB RAM, 512MB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-40°C~+55°C(-40°F~+131°F)
* Start up should be done at above -35°C
0~95% RH(non-condensing)
Humidity control /w AIR vent |
| Storage Temperature / Humidity |
-50°C~+60°C(-58°F~+140°F) / 0~90% RH |
| Certification |
IP66, NEMA4X, IK09 |
| Input Voltage |
PoE+(IEEE802.3at type 2, Class4) |
| Power Consumption |
PoE+: Max 23.5W, typical 13W |
| Mechanical |
| Couleur / Material |
White / Aluminum
Coupole de dôme à revêtment dur renforcés |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
ø200x80mm(ø7.87x3.15"), 1380g(3.04 lb) |
| Compatible Conduit hole / Gangbox |
None / single, double, 4" octagon, 4" square
Sold separately conduit hole accessory: SBP-060BA |
| Hanging Mount (Dome) |
SBP-200HMW |
| Ceiling Mount (Assy) |
SBP-150CMI/300CMI, SBP-300CMW1/900CMW, SBP-300CMTW, SBP-300CMTS |
| Wall Mount |
SBP-300WMW/WMW1, SBP-390WMW2 |
| Pole Mount |
SBP-300PMW2 |
| In-ceiling Mount |
SHD-2000FPW |
| Parapet Mount |
SBP-300LMW, SBP-156LMW1 |
| Corner Mount |
SBP-300KMW1 |
| Cabinet |
SBP-300NBW |
| Conduit Adaptor |
SBP-060BA |
| Certifications & Standards |
| EMC |
FCC 47 CFR 15 Subpart B Class A
ICES-3(A)/NMB-3(A)
CE/UKCA
- EN 55032 Class A, EN 50130-4
VCCI CISPR 32 Class A
RCM AS/NZS CISPR 32 Class A
KS C 9832 Class A , KS C 9835 |
| Safety |
UL 62368-1, CAN/CSA C22.2 NO. 62368-1
IEC 62471 |
| Environment |
EN IEC 63000
IEC 60529 IP66, IEC 62262 IK09
NEMA 250 type 4X |
| DORI (EN62676-4 standard) |
| Detect (25PPM/ 8PPF) |
45.9m(150.47ft) |
| Observe (63PPM/ 19PPF) |
18.3m(60.19ft) |
| Recognize (125PPM/ 38PPF) |
9.2m(30.09ft) |
| Identify (250PPM/ 76PPF) |
4.6m(15.05ft) |
