| Video |
| Imaging Device |
1/2.8" CMOS |
| Resolution |
1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 15fps (@2MP Max. 4fps) |
| Min. Illumination |
Couleur: 0.03Lux(F1.6, 1/30sec)
BW: 0Lux(IR LED on) |
| Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation |
| Lens |
| Focal Length (Zoom Ratio) |
3.2~10mm(3.1x) Vari-focale motorisée |
| Max. Aperture Ratio |
F1.6(Wide)~F2.9(Tele) |
| Angular Field of View |
H: 109°(Wide)~33°(Tele) / V: 58°(Wide)~18°(Tele) / D: 132°(Wide)~38°(Tele) |
| Min. Object Distance |
0.5m (1.64ft) |
| Focus Control |
Simple focus |
| Lens Type |
DC auto iris |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
0°~350° / 0°~67° / 0°~355° |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNR |
| Motion Detection |
4ea, polygonal zones |
| Privacy Masking |
6ea, rectangular zones |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
| Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics |
Détection de mouvement, Tampering, Defocus detection , Virtual area(Intrusion/Enter/Exit), Virtual line(Crossing/Direction) |
| Alarm I/O |
Input 1ea / Output 1ea |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input |
| Alarm Events |
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm output
Handover(PTZ preset) |
| Light Type |
IR LED (850nm) |
| Light Viewable Length |
20m(65.62ft) |
| Network |
| Ethernet |
RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Smart Codec |
WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(6 users) / Multicast
Streaming multiple(jusqu'à 3 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP |
| Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
| Security |
| OS / Firmware Protect |
Firmware encryption |
| User authentication |
Digest Authentication, Prevent brute-force attack |
| Network authentication |
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) |
| Secure Communication |
HTTPS, SRTP, WSS(Websocket secure) |
| Access Control |
Access control based on IP address |
| Data Protect |
Authentication information encryption, ZIP compression encryption |
| Audit |
User Access/System/Event log management |
| Device ID |
Device Certificate(Hanwha Private Root CA) |
| Secure Storage |
SDcard partition encrypt |
| General |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot 128GB |
| Memory |
512MB RAM, 256MB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-10°C~+55°C(+14°F ~ +131°F) / 0~90% RH |
| Storage Temperature / Humidity |
-30°C~+60°C(-22°F ~ +140°F) / 0~90% RH |
| Input Voltage |
PoE(IEEE802.3af, Class3), 12VDC |
| Power Consumption |
PoE: Max 7.70W, typical 6.00W
12VDC: Max 6.50W, typical 5.10W |
| Mechanical |
| Couleur / Material |
White / Plastic |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
ø119.8x98.8mm(ø4.72x3.89"), 320g(0.71 lb) |
| DORI (EN62676-4 standard) |
| Detect (25PPM/ 8PPF) |
Wide: 27.4m(89.85ft) / Tele: 128.8m(422.56ft) |
| Observe (63PPM/ 19PPF) |
Wide: 11.0m(35.94ft) / Tele: 51.5m(169.02ft) |
| Recognize (125PPM/ 38PPF) |
Wide: 5.5m(17.97ft) / Tele: 25.8m(84.51ft) |
| Identify (250PPM/ 76PPF) |
Wide: 2.7m(8.99ft) / Tele: 12.9m(42.26ft) |
