| Video |
| Imaging Device |
1/2.8" CMOS |
| Resolution |
2592x1944, 2560x1440, 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 30fps(@5MP Max. 5fps) |
| Min. Illumination |
Couleur: 0.05Lux(F2.0, 1/30sec, 30IRE)
BW: 0.005Lux(F2.0, 1/30sec, 30IRE) |
| Video Out |
USB: Micro USB Type B, 1280x720 for installation |
| Lens |
| Focal Length (Zoom Ratio) |
2.4mm Focale fixe |
| Max. Aperture Ratio |
F2.0 |
| Angular Field of View |
H: 123°/ V: 91°/ D: 159° |
| Min. Object Distance |
0.5m (1.64ft) |
| Focus Control |
Fixed |
| Lens Type |
Fixed IRIS |
| Mount Type |
M12 |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
0°~350° / -35°~70° / 0°~355° |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNRⅤ, WiseNRⅡ(Basée sur machines IA) |
| Motion Detection |
8ea, 8point polygonal zones |
| Privacy Masking |
32ea, 4point quadrangle zones |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
| Video Rotation |
Flip, Mirror, Hallway view(90°/270°) |
| Analytics |
Classification d'objets: Person/Vehicle
Attributes: Vehicle(Type:car/bus/truck/motorcycle/bicycle)
Support DetectionShot
Analyses d'événements basée AI
- Détection de mouvement*, Object detection, Virtual line*(Crossing/Direction), Virtual area*(Loitering/Intrusion/Enter/Exit)
Analytics events
- Defocus detection, Tampering, Virtual area(Appear/Disappear)
* Some of the video analytics only works with people and vehicle detection |
| Business Intelligence |
Basée sur machines IA: Comptage de personnes, Vehicle counting, Gestion de queue, Heatmap |
| Alarm Triggers |
Analytics, Network disconnect |
| Alarm Events |
When alarm trigger occurred
- File upload(image) : e-mail/FTP
- Notification : e-mail
- Recording : SD/SDHC/SDXC or NAS recording at event triggers
- Handover(PTZ preset, Send message by HTTP/HTTPS/TCP) |
| Network |
| Ethernet |
RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Smart Codec |
Manual(5ea area), WiseStreamⅢ(Basée sur machines IA) |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast
Streaming multiple(jusqu'à 5 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP (TCP, UDP Unicast) |
| Application Programming Interface |
ONVIF Profile S/G/T/M
SUNAPI(HTTP API) |
| Security |
| OS / Firmware Protect |
Secure boot, Signed firmware, Firmware encryption |
| User authentication |
Digest Authentication, Prevent brute-force attack |
| Network authentication |
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) |
| Secure Communication |
HTTPS, SRTP, WSS(Websocket secure) |
| Access Control |
Access control based on IP address |
| Data Protect |
Authentication information encryption, ZIP compression encryption |
| Audit |
User Access/System/Event log management |
| Device ID |
Device Certificate(Hanwha Private Root CA) |
| Secure Storage |
SDcard partition encrypt |
| Security Certificate |
Secure by default |
| General |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot 256GB |
| Memory |
2GB RAM, 1GB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-40°C~+55°C(-40°F~+131°F) / 0~95% RH
* Start up should be done at above -30°C
Humidity control /w Air vapor control |
| Storage Temperature / Humidity |
-50°C~+60°C(-58°F~+140°F) / 0~95% RH |
| Certification |
IP66, IK10, NEMA4X |
| Input Voltage |
PoE(IEEE802.3af, Class3) |
| Power Consumption |
PoE: Max 7W, typical 4.9W |
| Mechanical |
| Couleur / Material |
White / Aluminum
Bubble : Hard-coated dome |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
ø110x77mm(ø4.33x3.03"), 522g(1.15 lb) |
| Compatible Conduit hole / Gangbox |
SBD-110GP1 : Single, Double, 4" Octagon (Sold seperately) |
| Hanging Mount (Dome) |
SBP-120HMW |
| Backbox |
SBV-140BW |
| Certifications & Standards |
| EMC |
FCC 47 CFR 15 Subpart B Class A
ICES-3(A)/NMB-3(A)
CE/UKCA
- EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3
VCCI CISPR 32 Class A
RCM AS/NZS CISPR 32 Class A
KS C 9832 Class A , KS C 9835 |
| Safety |
UL 62368-1, CAN/CSA C22.2 NO. 62368-1
IEC/EN 62471 |
| Environment |
IEC/EN 63000
IEC/EN 60529 IP66, IEC/EN 62262 IK10 |
| DORI (EN62676-4 standard) |
| Detect (25PPM/ 8PPF) |
28.1m(92.35ft) |
| Observe (63PPM/ 19PPF) |
11.3m(36.94ft) |
| Recognize (125PPM/ 38PPF) |
5.6m(18.47ft) |
| Identify (250PPM/ 76PPF) |
2.8m(9.23ft) |
